Engine: | 4D34i |
General characteristics: | 4 Cylinder, Vertical in-line BSVI, inter-cooled, turbo-charged |
Engine Capacity: | 3907cc |
Engine Max output: | 170HP (125kW) @ 2500rpm |
Engine Max torque: | 520Nm @ 1500rpm |
Gearbox Model: | M036, Synchromesh |
No. of Gears: | 6 forward with overdrive+1 reverse |
Clutch Type: | Organic, Single dry plate, ⌀ 325mm |
Brake Type: | Dual Circuit, full air S-Cam type drum |
Auxiliary Brake: | Exhaust brake |
Electronic Brake: | Anti-lock Braking System (ABS) |
Front Axle: | Heavy-duty reverse elliot 'I' beam |
Rear Axle: | Fully floating type |
Suspension Type: | Parabolic suspension at front and rear |
Anti-roll bars: | Double acting telescopic shock absorber and anti-roll bars at front and rear |
Steering Type: | Power steering, adjustable and tiltable |
Tyre Type: | 235/75 R 17.5 tubeless tyres |
Battery: | 2x12V, 120Ah |
Fuel Tank/Filling Capacity: | 171L/160L |
Adblue Tank/Filling Capacity: | 43L/36L |
Seats: | Push back type (Option – High Head Rest) |
Seat Layout/capacity: | 2x1 layout with 26+2, 2x2 layout with 35+2, 2x2 layout with 39+2 High Head Rest |
Floor: | Marine grade plywood, Anti-skid vinyl top layer |
Passenger door: | In-swing, Automatic |
Windows: | Fixed glass |
Emergency exit: | Door at rear RHS, rear breakable glass, all windows breakable |
Emergency kit: | Fire extinguisher (5kg x2), First-Aid kit |
Hatrack: | Modular hatrack with individual AC vents and service sets (Option – free flow) |
Lights: | 4+1 standard LED lights with integrated night lamp distributed through saloon area |
Safety features: | Seat belts, provision for CCTV, GPS, RFID and navigator, light at entry area , emergency alarm |
Fitments: | Notice Board |
